The Starcon crossbar transport anchor is designed with an internal thread for transporting and fastening concrete elements. The transport with cross-pin can be used to lift and secure wall or tunnel elements and can be attached directly to the reinforcement mesh in precast concrete elements.
The cross-hole transport anchor is available with a metric thread, which makes it easy to attach wire rope straps and threaded lifting equipment by screwing these onto the transport anchor. The cylindrical internal thread assembly enables a reliable connection to the wire rope strap, ensuring an efficient and safe lifting operation.
Areas of application: Concrete elements, beams or columns.
The cross-hole transport anchor is available with a metric thread, which makes it easy to attach wire rope straps and threaded lifting equipment by screwing these onto the transport anchor. The cylindrical internal thread assembly enables a reliable connection to the wire rope strap, ensuring an efficient and safe lifting operation.
Areas of application: Concrete elements, beams or columns.
Advantages: Low dead weight
Quick on and off lifting equipment
Load group: 0.5t – 2.5t
Technical information: CE marking according to MD 2006/42 EF
Starcon product is designed according to EN13155-2009 and follows the guidelines of VDI/BV-BS 6205 and DS/CEN/TR 15728.
EPD: Our Environmental Product Declarations (EPDs) are available in the LCA NO calculator/software. These EPDs have been prepared in strict accordance with ISO 14025 and EN 15804 standards.
Download the EPDs from the LCA database:
Untreated Products: Starcon Lifting and Handling Systems for Concrete elements - Untreated - EPD Norge
Surface treated Products: Starcon Lifting and Handling Systems for Concrete elements - Surface Treated. - EPD Norge
- Marking: CE-marked, Thread size, batch code, load group + S(Starcon)
- Finish: Electro-galvanized - Corrosion class C3 - ISO 12944-2.
Note: The delivery time for the individual products is estimated and if the desired quantity is not in stock, please contact CERTEX Danmark A/S – Starcon for information on the applicable delivery time.
